Platform for automotive engineering
Remote Vehicle Testing
Get access to your data. No matter where, no matter when. The best data acquisition in the car, worldwide.
Individual configuration
Bidirectional data exchange: configuration and data
Previous
Next
Previous
Next
Your benefits
Benefit from our well-established system in a range of areas.
Complete end-to-end system
The Flea 4 is embedded in an integrated end-to-end system consisting of the end device in the vehicle and the cloud service in the backend.
Everything via remote
The system can be used and managed completely remotely. Configurations, operations, results, new software, new drivers, and security updates – 100% possible from your desk and remotely.
Over the air
New compact services and algorithms can be developed and distributed remotely. This keeps the overall system up-to-date and attractive over time.
Complete end-to-end system
Everything via remote
Over the air
Connectivity
Our system is compatible with common cloud computing platforms:
- Pantaris (ETAS GmbH)
- Bosch IoT insights
- Microsoft Azure
- Customer Backend
Versatile & flexible
Whether in the vehicle, in the lab, or on the test track/road, logging and diagnostics are highly configurable.
Expandable
Extensions or even complete developments are possible at the customer's request. Our hardware allows retrofitting by means of extension boards (FlexRay, PLC) allowing a subsequent adaptation to hardware requirements.
Connectivity
Versatile & flexible
Expandable
Easy to manage
Everything easily managed via device management, monitoring, reporting and over-the-air update.
Form factor & installation
The Flea 4 stands out with its compact size - it offers the greatest functionality in the most compact of spaces. This makes it easy to install in the vehicle, practically plug & play.
Cost efficiency
The unit costs and thus the investments are low and payable via a term contract in actual use. This lowers your barrier to entry and costs only as long as you actually benefit.
Easy to manage
Form factor & installation
Cost efficiency
In the lab
On the road
On the test bench
Ideal solutions
On the test bench
On the road
In the
lab
As a leading manufacturer of high-performance data loggers we have been working closely for 20 years with renowned companies in the automotive industry in the field of innovative mobility concepts. Our services range from individual hardware and software solutions to internationally operating customer service and the development of test environments.
Increasing global urbanization and digitalization demand safe automated mobility solutions. Our systems serve in many situations such as sporadic error identification, quality and utilization analysis.
Increasing global urbanization and digitalization demand safe automated mobility solutions. Our systems serve in many situations such as sporadic error identification, quality and utilization analysis.
Flea 4+
Use Cases
Sporadic error identification
The occurrence of sporadic errors can be a major problem, especially when new models are introduced. A smart configuration can detect these and record them together with the correlating context.
Endurance run
Testing in the vehicle endurance run. Development and testing to meet the highest demands. Obtaining vehicle data remotely from anywhere in the world.
Quality assurance
Testing and ensuring the functionality is as specified, from the individual component to the overall system. Acquiring vehicle data intelligently and making it available enables continuous and sustainable assurance of its level of maturity.
Live data
Live data is indispensable in the transformation of the automobile into a digital entity. Through free configuration, you decide which vehicle data is streamed. In combination with streaming from the cloud, computationally intensive and latency-sensitive functions can be outsourced.
Customer behavior
Data on customer usage, satisfaction & behavior can be collected. Information on the use of features can be collected and its subsequent evaluation can lead to insights for further and new developments.
PLC monitoring*
Logging of charging communication to test interoperability between EV vehicle and charging point.
*in development
*in development
Documentation
Documents at a glance
Are you interested in further documents? Visit our download area.
Hardware features
All at a glance
With the LED status display on the front of the Flea 4+, you have a more detailed view of the status of the system.
Technical data
System
Ports
Connectivity
System
System
Operating system: Embedded Linux (Yocto-based)
Operating voltage: 12 / 24 V
Operating temperature: -40°C … +85°C
Dimensions: 152 mm x 107 mm x 36 mm incl. main connection
Start Options: Ignition, CAN (activity), RTC, modem ring
Operating voltage: 12 / 24 V
Operating temperature: -40°C … +85°C
Dimensions: 152 mm x 107 mm x 36 mm incl. main connection
Start Options: Ignition, CAN (activity), RTC, modem ring
Power Supply Unit
Overvoltage protection: 36 V
Standby: < 0.5 mA @ 12 V
Idle state (warm start): < 10 mA @ 12 V
Working mode: < 500 mA @ 12 V
Standby: < 0.5 mA @ 12 V
Idle state (warm start): < 10 mA @ 12 V
Working mode: < 500 mA @ 12 V
System
Operating system: Embedded Linux (Yocto-based)
Operating voltage: 12 / 24 V
Operating temperature: -40°C … +85°C
Dimensions: 152 mm x 107 mm x 36 mm incl. main connection
Start Options: Ignition, CAN (activity), RTC, modem ring
Operating voltage: 12 / 24 V
Operating temperature: -40°C … +85°C
Dimensions: 152 mm x 107 mm x 36 mm incl. main connection
Start Options: Ignition, CAN (activity), RTC, modem ring
Power Supply Unit
Overvoltage protection: 36 V
Standby: < 0.5 mA @ 12 V
Idle state (warm start): < 10 mA @ 12 V
Working mode: < 500 mA @ 12 V
Standby: < 0.5 mA @ 12 V
Idle state (warm start): < 10 mA @ 12 V
Working mode: < 500 mA @ 12 V
Ports
ELO-54
5 x CAN-FD
1 x Automotive Ethernet (100 BASE-TX)
1 x DoIP ISO 13400 (100 BASE-TX)
1 x FlexRay A / B channels
3 x Analog input (0-60 V)
2 x Digital output (Open Drain)
1 x Digital output (High Side Switch)
1 x I2C
2 x RS232
1 x Automotive Ethernet (100 BASE-TX)
1 x DoIP ISO 13400 (100 BASE-TX)
1 x FlexRay A / B channels
3 x Analog input (0-60 V)
2 x Digital output (Open Drain)
1 x Digital output (High Side Switch)
1 x I2C
2 x RS232
USB
USB-C 2.0 (Host or Client / OTG)
Antenna
2 x 2G / 3G / 4G Antenna Fakra
1 x GPS Antenna Fakra
1 x WLAN ex. Antenna(optional)
1 x GPS Antenna Fakra
1 x WLAN ex. Antenna(optional)
ELO-54
5 x CAN-FD
1 x Automotive Ethernet (100 BASE-TX)
1 x DoIP ISO 13400 (100 BASE-TX)
1 x FlexRay A / B channels
3 x Analog input (0-60 V)
2 x Digital output (Open Drain)
1 x Digital output (High Side Switch)
1 x I2C
2 x RS232
1 x Automotive Ethernet (100 BASE-TX)
1 x DoIP ISO 13400 (100 BASE-TX)
1 x FlexRay A / B channels
3 x Analog input (0-60 V)
2 x Digital output (Open Drain)
1 x Digital output (High Side Switch)
1 x I2C
2 x RS232
USB
USB-C 2.0 (Host or Client / OTG)
Antenna
2 x 2G / 3G / 4G Antenna Fakra
1 x GPS Antenna Fakra
1 x WLAN ex. Antenna(optional)
1 x GPS Antenna Fakra
1 x WLAN ex. Antenna(optional)
Connectivity
Mobile
LTE CAT4 (150 Mbit/s download, 50 Mbit/s upload)
EMEA Region Bands 1, 3, 5, 7, 8, 20
HSDPA category 24, HSUPA category 6
MIMO 2 x 2 / RX diversity
3G / 2G, Quadband fallback
EMEA Region Bands 1, 3, 5, 7, 8, 20
HSDPA category 24, HSUPA category 6
MIMO 2 x 2 / RX diversity
3G / 2G, Quadband fallback
WLAN
LTE CAT4 (150 Mbit/s download, 50 Mbit/s upload)
EMEA Region Bands 1, 3, 5, 7, 8, 20
HSDPA category 24, HSUPA category 6
MIMO 2 x 2 / RX diversity
3G / 2G, Quadband fallback
EMEA Region Bands 1, 3, 5, 7, 8, 20
HSDPA category 24, HSUPA category 6
MIMO 2 x 2 / RX diversity
3G / 2G, Quadband fallback
Ethernet
10 / 100 / 1000 BASE-TX
Bluetooth
BT, BLE 4.2
Mobile
LTE CAT4 (150 Mbit/s download, 50 Mbit/s upload)
EMEA Region Bands 1, 3, 5, 7, 8, 20
HSDPA category 24, HSUPA category 6
MIMO 2 x 2 / RX diversity
3G / 2G, Quadband fallback
EMEA Region Bands 1, 3, 5, 7, 8, 20
HSDPA category 24, HSUPA category 6
MIMO 2 x 2 / RX diversity
3G / 2G, Quadband fallback
WLAN
LTE CAT4 (150 Mbit/s download, 50 Mbit/s upload)
EMEA Region Bands 1, 3, 5, 7, 8, 20
HSDPA category 24, HSUPA category 6
MIMO 2 x 2 / RX diversity
3G / 2G, Quadband fallback
EMEA Region Bands 1, 3, 5, 7, 8, 20
HSDPA category 24, HSUPA category 6
MIMO 2 x 2 / RX diversity
3G / 2G, Quadband fallback
Ethernet
10 / 100 / 1000 BASE-TX
Bluetooth
BT, BLE 4.2
Features
Measure
Monitoring
CAN/CAN-FD, FlexRay
Measurement
CCP, XCPon CAN/CAN-FD, Ethernet, FlexRay (optional)
Continuous, Triggered, Streaming
MDF, ASC, CSV, Streaming (Device ↔ Cloud)
Performance
Diagnostics
UDS
ISO 14229
ISO-TP
ISO 15765: CAN/CAN-FD, FlexRay
DoIP
ISO 13400
OBD2
ISO 15031
Lua Script-based Diagnostic Sequences
Low-Code-Editor available
Seamless integration of existing DiagRA® D Test Sequences
Our Service
Data Access (REST-API)
Storage
Azure Blob Storage
Azure Data Lake Storage Gen2
Bosch IoT Insights
Pantaris (ETAS GmbH)
Custom upload
Azure Data Lake Storage Gen2
Bosch IoT Insights
Pantaris (ETAS GmbH)
Custom upload
Account Management
Device Management
Fleet Management
Reporting
Software update over the air
Service Desk
Device Management
Fleet Management
Reporting
Software update over the air
Service Desk
4G
Wi-Fi
Bluetooth
Data Streaming (MQTT)
Wi-Fi
Bluetooth
Data Streaming (MQTT)
CAN/FlexRay Monitoring
CCP
XCP on CAN/CAN-FD/FlexRay/Ethernet
Camera support
PLC Monitoring (soon available)
CCP
XCP on CAN/CAN-FD/FlexRay/Ethernet
Camera support
PLC Monitoring (soon available)
Development
Consultance
Support
Consultance
Support
Script Diagnostics
(UDS, OBD, DoIP, J1939)
(UDS, OBD, DoIP, J1939)
DCC-Client
Flea Cockpit
Flea Cockpit
Our Service
Data Access (REST-API)
Storage
Azure Blob Storage
Azure Data Lake Storage Gen2
Bosch IoT Insights
Pantaris (ETAS GmbH)
Custom upload
Azure Data Lake Storage Gen2
Bosch IoT Insights
Pantaris (ETAS GmbH)
Custom upload
CAN/FlexRay Monitoring
CCP
XCP on CAN/CAN-FD/FlexRay/Ethernet
Camera support
PLC Monitoring (soon available)
CCP
XCP on CAN/CAN-FD/FlexRay/Ethernet
Camera support
PLC Monitoring (soon available)
Account Management
Device Management
Fleet Management
Reporting
Software update over the air
Service Desk
Device Management
Fleet Management
Reporting
Software update over the air
Service Desk
4G
Wi-Fi
Bluetooth
Data Streaming (MQTT)
Wi-Fi
Bluetooth
Data Streaming (MQTT)
Development
Consultance
Support
Consultance
Support
Script Diagnostics
(UDS, OBD, DoIP, J1939)
(UDS, OBD, DoIP, J1939)
DCC-Client
Flea Cockpit
Flea Cockpit
Teamwork
Remote Bridge by Bosch Engineering
Efficient vehicle development with Bosch Engineering: Thanks to Remote Bridge, development teams, vehicles and measurement data are networked, thus simplifying the testing and development process via remote access.
Flea 4+ integrated into the ETAS tool chain.
The strengths of ETAS measurement technology experience a new impulse through the use of IoT in the form of Flea 4+. This enables a new experience in automotive development with a focus on cost efficiency and sustainability of solutions.
Right from the start your experienced partner
CarMedialab offers you the right software. Your advantage: all components have been repeatedly tested and are already successfully in use. Plus, our systems are available immediately.
