Platform for remote vehicle testing

Automotive Engineering

Get access to your data. No matter where, no matter when. The best data acquisition in the car, worldwide.

Individual configuration

Bidirectional data exchange: configuration and data

Your benefits

Benefit from our well-established system in a range of areas.

Complete end-to-end system

The Flea 4 is embedded in an integrated end-to-end system consisting of the end device in the vehicle and the cloud service in the backend.

Everything via remote

The system can be used and managed completely remotely. Configurations, operations, results, new software, new drivers, and security updates – 100% possible from your desk and remotely.

Over the air

New compact services and algorithms can be developed and distributed remotely. This keeps the overall system up-to-date and attractive over time.

Connectivity

Our system is compatible with common cloud computing platforms:
– Pantaris (ETAS GmbH)
– Bosch IoT insights
– Microsoft Azure
– Customer Backend

Versatile & flexible

Whether in the vehicle, in the lab, or on the test track/road, logging and diagnostics are highly configurable.

Expandable

Extensions or even complete developments are possible at the customer’s request. Our hardware allows retrofitting by means of extension boards (FlexRay, PLC) allowing a subsequent adaptation to hardware requirements.

Easy to manage

Everything easily managed via device management, monitoring, reporting and over-the-air update.

Form factor & installation

The Flea 4 stands out with its compact size – it offers the greatest functionality in the most compact of spaces. This makes it easy to install in the vehicle, practically plug & play.

Cost efficiency

The unit costs and thus the investments are low and payable via a term contract in actual use. This lowers your barrier to entry and costs only as long as you actually benefit.

In the lab

On the road

On the test bench

Ideal solutions

On the test bench

On the road

In the

lab

As a leading manufacturer of high-performance data loggers we have been working closely for 20 years with renowned companies in the automotive industry in the field of innovative mobility concepts. Our services range from individual hardware and software solutions to internationally operating customer service and the development of test environments.

Increasing global urbanization and digitalization demand safe automated mobility solutions. Our systems serve in many situations such as sporadic error identification, quality and utilization analysis.

Flea 4+

Use cases

Sporadic error identification

The occurrence of sporadic errors can be a major problem, especially when new models are introduced. A smart configuration can detect these and record them together with the correlating context.

Endurance run

Testing in the vehicle endurance run. Development and testing to meet the highest demands. Obtaining vehicle data remotely from anywhere in the world.

Quality assurance

Testing and ensuring the functionality is as specified, from the individual component to the overall system. Acquiring vehicle data intelligently and making it available enables continuous and sustainable assurance of its level of maturity.

Live data

Live data is indispensable in the transformation of the automobile into a digital entity. Through free configuration, you decide which vehicle data is streamed. In combination with streaming from the cloud, computationally intensive and latency-sensitive functions can be outsourced.

Customer behavior

Data on customer usage, satisfaction & behavior can be collected. Information on the use of features can be collected and its subsequent evaluation can lead to insights for further and new developments.

PLC monitoring*

Logging of charging communication to test interoperability between EV vehicle and charging point.
*in development

Documentation

Documents at a glance

Are you interested in further documents? Visit our download area.

Hardware features

All at a glance

With the LED status display on the front of the Flea 4+, you have a more detailed view of the status of the system.

Technical data

System

Ports

Connectivity

System

Ports

Connectivity

Features

Measure

Monitoring

CAN/CAN-FD, FlexRay

Measurement

CCP, XCPon CAN/CAN-FD, Ethernet, FlexRay (optional)

Continuous, Triggered, Streaming

MDF, ASC, CSV, Streaming (Device ↔ Cloud)

Performance

Diagnostics

UDS

ISO 14229

ISO-TP

ISO 15765: CAN/CAN-FD, FlexRay

DoIP

ISO 13400

OBD2

ISO 15031

Lua Script-based Diagnostic Sequences

Low-Code-Editor available

Seamless integration of existing DiagRA® D Test Sequences

Our service

Data

Data Access (REST-API) Storage

3rd Party Interface

Azure Blob Storage
Azure Data Lake Storage Gen2
Bosch IoT Insights
Pantaris (ETAS GmbH)
Custom upload

Managed

Account Management
Device Management
Fleet Management
Reporting
Software update over the air
Service Desk

Connectivity

4G
Wi-Fi
Bluetooth
Data Streaming (MQTT)

Logging (Monitoring/Measurements)

CAN/FlexRay Monitoring
CCP
XCP on CAN/CAN-FD/FlexRay/Ethernet
Camera support
PLC Monitoring (soon available)

Engineering

Development
Consultance
Support

Diagnostics

Script Diagnostics
(UDS, OBD, DoIP, J1939)

Tooling

DCC-Client
Flea Cockpit

Our service

Teamwork

Remote Bridge by Bosch Engineering

Efficient vehicle development with Bosch Engineering: Thanks to Remote Bridge, development teams, vehicles and measurement data are networked, thus simplifying the testing and development process via remote access.

Learn more

Flea 4+ integrated into the ETAS tool chain.

The strengths of ETAS measurement technology experience a new impulse through the use of IoT in the form of Flea 4+. This enables a new experience in automotive development with a focus on cost efficiency and sustainability of solutions.

Learn more

Right from the start your experienced partner

CarMedialab offers you the right software. Your advantage: all components have been repeatedly tested and are already successfully in use. Plus, our systems are available immediately.
